Supply Voltage

10.5 - 31.2 VDC (12/24V systems)

Max Wind Speed

100 knots (51 m/s)

Power Consumption typical

18W

Warranty Period

2 Years

Power Consumption max

20W

Max Range, scale

24 NM

Rotation speed

24 RPM

Operating Temperature Range

-25° to + 55°C (-13° to +130°F)

Beam width

4.9° H x 25° V

Weight

5.9 kg (13 lbs) without cable

Min Range, scale

50 m / 200 ft / 50 yd

Dimensions Diameter

510mm (20")

Dimensions W x H x D

510mm dia x 223 mm H. (20" dia x 8.8" H)

Recommended Fuse Rating

5A

Humidity

95% RH at 35°C (95°F)

Approvals Compliance

FCC, Part 47 CFR 80 and 90: RED, Article 3 of Directive 99/5/EC: CE: EN, EN302-248 V2.1.1: Industry Canada, RSS238: RCM (C-Tick): IEC60945 Sec 9.2,9.3, 10.3-10.9, 11.2: IEC60950 Electrical Safety

Radar Modes

Harbour, Offshore, Weather, North Up, Course Up, Relative motion, True Motion

Waterproofrating

IPX6

Interface

Lowrance MFD

Radar Technology

Pulse Compression
